Thermal Shock Test Chamber Machine for Lithium Battery Testing
The thermal shock test machine simulates that the battery is placed in a high temperature box with natural convection or forced ventilation, and the temperature is raised to the set test temperature at a certain heating rate and maintained for a certain period of time. The hot air circulation system can ensure uniform working temperature distribution.
Specification：
|
Product Name |
Thermal shock test chamber machine |
|
Inner box size |
400x400x450mm (width x depth x height) (the size of the test box can be customized according to requirements) |
|
Outer box size |
W650xD920xH30mm |
|
Temperature range |
normal temperature~200℃ |
|
Temperature display accuracy |
0.1℃ |
|
Temperature stability |
±1.0℃ |
|
Temperature uniformity |
±2℃ |
|
Heating time |
(5±2)℃/min, (average temperature rise, non-linear no-load) |
|
Temperature control table |
programmable temperature controller, which can control the total time of heating, which is different from ordinary temperature control table. |
|
Inner box material |
stainless steel plate |
|
Outer box material |
cold-rolled steel plate with paint |
|
Insulation material |
high-efficiency compressed glass wool |
|
Insulation device |
no fuse switch, over-temperature protection switch, fuse |
|
Power supply |
1∮, 220V, 20A |
|
Safety devices |
secondary over-temperature alarm, MCCB overload protection, etc. |
|
Exhaust flue |
blade design can adjust the air volume |
|
Air supply circulation system |
convection air supply circulation system |
