5V10mA Lab Coin Cell Battery Tester with Dual Testing Range
It is an eight-channel battery analyzer to analyze small coin cells from 0.001 mA to 10 mA, up to 5V. Each channel of the analyzer has independent constant-current and constant-voltage source, which can be programmed and controlled by computer software. This system provides most applications in battery testing fields such as electrode materials research, battery performance test, small-scale battery formation, capability grading, battery pack testing and etc.
|
Item |
Technology parameters |
|
|
Model |
AOT-BTS-5V10mA Coin cell tester |
|
|
Input Power |
AC 220V ±10% 50Hz |
|
|
resolution |
AD：16bit；DA：16bit |
|
|
Input Resistance |
≥10 GΩ |
|
|
Input Power |
25W |
|
|
Voltage |
Constant Voltage Range |
25mV~5V |
|
Discharge Min Voltage |
0V |
|
|
Accuracy |
± 0.05% of FS |
|
|
Stability |
± 0.05% of FS |
|
|
Current |
Per Channel Current Range |
|
|
Accuracy |
± 0.05% of FS |
|
|
Constant voltage cutoff current |
Range1：2uA；Range2：0.02mA |
|
|
Stability |
± 0.05% of FS |
|
|
Power |
Per Channel Output Power |
0.05W |
|
Stability |
± 0.1% of FS |
|
|
Time |
Current Response Time |
1ms (0-Full Range) |
|
Step Time Range |
≤(365*24 )hour/step， Time Form Support 00：00：00(h、min:s、ms) |
|
|
Data Recording |
Record Condition |
Minimum Time Interval: 100ms |
|
Minimum Voltage Interval: 10mV |
||
|
Minimum current interval：Range1：2uA；Range 2：0.02mA |
||
|
Record Frequency |
10Hz |
|
|
Charge |
Charge Mode |
Constant Current Charge、Constant Voltage Charge、 Constant Current and Constant Voltage Charge、CPC |
|
End Conditon |
Voltage, current, relative time, capacity -△V |
|
|
Discharge |
Discharge Mode |
CCD、CPD、CRD |
|
End Condition |
Voltage、Current、Relative Time、Capacity -△V |
|
|
Pulse |
charge |
CCC, CPC |
|
Discharge |
CCD, CPC |
|
|
Min Pulse Width |
500ms |
|
|
Pulse number |
A single pulse step supports 32 different pulses |
|
|
Automated Switch |
Automated swith from charge to discharge for each pulse |
|
|
End Condition |
Voltage, Test Time |
|
|
Cycle |
Loop Measure Range |
1~65535 times |
|
Max Steps Per Loop |
254 |
|
|
Nested Loop |
Nested loop Function，Max Support 3 Layers |
|
|
Protection |
Software Protection |
Power-down Data Protection |
|
Off-line Testing Function |
||
|
Setting Protection Condition，Setting Parameter：Low Voltage limit、Upper Voltage limit、Low Current limit、Upper Current limit、Delay Time |
||
|
Hardware Protection |
Additional Anti-reverse Protection Model |
|
|
Channel Features |
Constant Current Source and Constant Voltage Source with Independent pairs of Closed-loop Structure |
|
|
Channel Control Mode |
Independent Control |
|
|
DCIR testing |
Support |
|
|
Voltage and Current Testing Sample |
4-wire connecting |
|
|
Noise |
<85dB |
|
|
Database |
MySQL Database |
|
|
A Means of Communication of Upper Machine |
TCP/IP Protocol |
|
|
Data Output |
EXCEL、TXT、Graph |
|
|
Communication Interface |
Ethernet Port |
|
|
Per Unit Main Channels No. |
8 |
|
|
Dimensions |
250*200*60(mm) |
|
