18650 Cylindrical Battery Automatic Sorting Machine
Model：AOT-ST-20C
SystemOverview
20 channels automatic loading and sorting machine is mainly for automatic testing the voltage and internal resistance of cylindrical batteries, such as 18650, 26650, 32650, 21700. The level of each battery cell is calculated according to the software setting of the host computer, and different grades of batteries are transferred to different channels according to the determination result, thereby achieving automatic sorting of battery products.
The automatic sorting equipment is composed of a feeding mechanism, a testing mechanism, an automatic sorting, and a receiving mechanism.
The machine system designs and develops the upper computer software according to the user's requirements, and automatically sorts and collects the battery cores into their corresponding channels according to the set group information.
Technical Parameter
|
Name |
20 channels sorting machine for 18650 battery |
|
Voltage source |
AC220V±10% 50Hz |
|
Power |
≤3KW |
|
Compressed air |
0.5～0.8Mpa |
|
Application |
18650 battery automatic sorting, optional for 32650/21700/26650 |
|
Sortingchannel |
20 channels |
|
Open circuit voltage |
Accuracy +/-0.01% rdg, display resolution 0.1 millivolt |
|
AC internal resistance |
Accuracy +/-0.5% rdg, display resolution 0.1 millivolt |
|
Equipment capacity/speed |
About 6500pcs-6800pcs |
|
NG equipment failure rate |
≤ 2%（Failure caused only by equipment） |
|
Workign humidity |
≤85％ |
|
Working temperature range |
25℃±5℃ |
|
Computer |
1 set |
|
Probability of product damage |
≤0.1% |
|
Internal resistance tester |
HK3561 (Hioki 3561 optional) |
|
Printer |
Optional for battery factory |
|
Code reader/ Scanning device |
Optonal(Keyence SR-1000W) |
|
Maximum size of equipment |
L1930mm*W1650mm*H1500mm |
|
Weight |
About 400kg |
