Manual Hydraulic Coin Cell Crimping Machine for Lab CR20XXButton Battery Research
FAQ
Q: Can we put it inside the glove box?
A: Yes, it can be used inside the glove box, because of compact size and light weight.
Q:Will the hydraulic system leakage?
A:It will no leakage if you use it without abnormal operation.
Q: What’s the main advantage of this crimper?
A: Accurate molding, Convenient operation, Easy maintenance, Small size, Good appearance.
Brief Introduction:
The button battery sealing machine is mainly used for battery materials sample production in laboratory, it is for coin cell battery and capacitor research and stainless steel cases crimping. It can also be used for small batch trial production in factories.
Equipped with different molds can be used for coin cell cases disassembly and other picking research, battery electrode sheet pressing, battery material powder pressing and other operations.
Features:
* Built-in safety overflow valve, can adjust the pressure as needed, you can set the limited pressure to prevent damage caused by excessive pressure caused by misoperation, ensuring the safety of the machine.
*Embeded pressure gauge can observe and accurately control the sealing pressure.
* Hydraulic drive, pressure up to 8T, crimping process without vibration, no leakage.
* Specially designed hydraulic structure for saving labor.
*Precise mold design ensures accurate and reliable sealing, the strong steel structure design is stable and safe to use.
* Small size, easy to operate, can be placed in the glove box.
Main Parameters:
|
Model |
Hydraulic Crimping Machine AOT-HCM-20 |
|
Appication |
Mainly for coin cell lab research |
|
Crimping Die |
1 One set of crimping die for CR20xx series coin cell cases, include CR2032,CR2025,and CR2016 2 Optional die available for crimping CR2325,CR2450,AG3,AG5 3 PTFE Anti-Corrosion Core prevents coin cells from being short circuited |
|
Advantages |
The lower die with high precision positioning ring spacing, control the battery package height.
The upper die is provided with a sealing cup inner screw spring mechanism,ensure in case the battery sealing clamp can not be removed,only the top screw clockwise and the button battery out. 3 By using aluminum alloy and high strength steel, surface after the environmental protection electroplating processing will never rust. |
|
Handle Pressure |
<5.5kg |
|
Max Pressure |
200kg/cm2 |
|
Working Pressure |
80-100kg/cm2 |
|
Dimension(L*W*H) |
235mm*170mm*330mm |
|
Weight |
27kg |
|
Shipping Weight |
About35kg |
|
Warranty |
One Year limited warranty with lifetime support |
|
Service |
Oversea after-sales service is available |
