300mm Continuous Battery Electrode Coating Machine for Manufacturing

The continuous experimental battery electrode coating machine is specially used for coating the surface of the Al foil and copper foil.
  • Item NO.:

    AOT-CCM-300
  • Lead Time:

    10-25days
  • Product Orgin:

    China
  • Shipping Port:

    Xiamen, China
  • Payment:

    T/T, WesternUnion, MoneyGram, Paypal, Visa
  • Product Detail

300mm Continuous Battery Electrode Coating Machine AOT-CCM-300



Description:

The continuous experimental battery electrode coating machine is specially used for coating the surface of the aluminum foil and copper foil, which can realize a very uniform thin coating on the surface of the substrate. It is automatically dried by the heating oven on the coater. This equipment can realize continuous coating, and is suitable for battery production R & D experiments and sample production, etc., it is also widely used in other industries such as film, papermaking and composite materials, and has high experimental production efficiency.



Features:

1. Automatic unreeling and rewinding after coating;

2. Rewinding automatic correction system makes rewinding more neat and beautiful;

3. Equipped with drying system, heating temperature PID adjustable;

4. The coating tension is adjustable;

5. High coating accuracy;

6. Optional coating width according to customer needs.



Specifications:

Model

Continuous Battery Electrode Coating Machine AOT-CCM-300

Source voltage

AC 380V, 50HZ (Can be customized)

Max power

9000W

Warranty

One Year limited manufacturewarranty with lifetime technicalsupport

The base width

300mm

Coating width

30mm-280mm adjustable

Coating mode

Continuous coating

Coating speed

100mm-600mm, adjustable

Applicable foil thickness

Aluminum foil : 10-30um

Copper foil : 6-20um

Coating thickness accuracy

±3um

Coating length accuracy

±1mm

Coating roller diameter

100mm

Coating rollerthrob

≤2um

Unwinding roller diameter

280mm

Unwinding tension control

5-50N, adjustable

winding roller diameter

280mm

winding tension control

5-50N, adjustable (AC motor active winding)

Scraper positioning accuracy

±1 cm (micrometer)

Error-correction accuracy

±0.5mm

Applicable slurry viscosity

1500-15000cps

Oven temperature

Max150°C adjustable, with accuracy ±1°C,

Independent PID adjustable

Oven length

2000mm (can be custom)

Weight

About500kg

Dimension(L*W*H)

About2800*800*900mm

Battery Electrode Coating Machine for Manufacturing

Battery Electrode Continuous Coating Process

Battery Electrode Coater Machine
