5V50mA Coin Cell Testing Equipment for Lab Lithium Battery Research
1. The battery tester is according to the international standard design, battery tester each channel has an independent constant-current source and constant-voltage source. It is used to test rechargeable( Lithium-ion battery,Ni-MH battery, Ni-CD battery and polymer battery, etc.) pack battery, and so on.
2. Battery tester's internal electrical power supply uses the high efficiency switching power supply, the energy conservation effect remarkable, each power tube has the independent protection circuit, guarantees the Equipment works with safety and reliability.
3. Measure adopts four wire method, decrease contact error, increase measure precision.
4. Battery tester each channel is independent; With high efficient cooling system, Equipment can work 24 hours with full load.
|
Item |
Technology parameters |
|
|
Model |
AOT-BTS-5V50mA Coin cell tester |
|
|
Input Power |
AC 220V ±10% 50Hz |
|
|
resolution |
AD：16bit；DA：16bit |
|
|
Input Resistance |
≥10 GΩ |
|
|
Input Power |
25W |
|
|
Voltage |
Constant Voltage Range |
25mV~5V |
|
Discharge Min Voltage |
0V |
|
|
Accuracy |
± 0.05% of FS |
|
|
Stability |
± 0.05% of FS |
|
|
Current |
Per Channel Current Range |
|
|
Accuracy |
± 0.05% of FS |
|
|
Constant voltage cutoff current |
Range1：10uA；Range2：0.1mA |
|
|
Stability |
± 0.05% of FS |
|
|
Power |
Per Channel Output Power |
0.25W |
|
Stability |
± 0.1% of FS |
|
|
Time |
Current Response Time |
1ms (0-Full Range) |
|
Step Time Range |
≤(365*24 )hour/step， Time Form Support 00：00：00(h、min:s、ms) |
|
|
Data Recording |
Record Condition |
Minimum Time Interval: 100ms |
|
Minimum Voltage Interval: 10mV |
||
|
Minimum current interval：Range1：10uA；Range 2：0.1mA |
||
|
Record Frequency |
10Hz |
|
|
Charge |
Charge Mode |
Constant Current Charge、Constant Voltage Charge、 Constant Current and Constant Voltage Charge、CPC |
|
End Conditon |
Voltage, current, relative time, capacity -△V |
|
|
Discharge |
Discharge Mode |
CCD、CPD、CRD |
|
End Condition |
Voltage、Current、Relative Time、Capacity -△V |
|
|
Pulse |
charge |
CCC, CPC |
|
Discharge |
CCD, CPC |
|
|
Min Pulse Width |
500ms |
|
|
Pulse number |
A single pulse step supports 32 different pulses |
|
|
Automated Switch |
Automated swith from charge to discharge for each pulse |
|
|
End Condition |
Voltage, Test Time |
|
|
Cycle |
Loop Measure Range |
1~65535 times |
|
Max Steps Per Loop |
254 |
|
|
Nested Loop |
Nested loop Function，Max Support 3 Layers |
|
|
Protection |
Software Protection |
Power-down Data Protection |
|
Off-line Testing Function |
||
|
Setting Protection Condition，Setting Parameter：Low Voltage limit、Upper Voltage limit、Low Current limit、Upper Current limit、Delay Time |
||
|
Hardware Protection |
Additional Anti-reverse Protection Model |
|
|
Channel Features |
Constant Current Source and Constant Voltage Source with Independent pairs of Closed-loop Structure |
|
|
Channel Control Mode |
Independent Control |
|
|
DCIR testing |
Support |
|
|
Voltage and Current Testing Sample |
4-wire connecting |
|
|
Noise |
<85dB |
|
|
Database |
MySQL Database |
|
|
A Means of Communication of Upper Machine |
TCP/IP Protocol |
|
|
Data Output |
EXCEL、TXT、Graph |
|
|
Communication Interface |
Ethernet Port |
|
|
Per Unit Main Channels No. |
8 |
|
|
Dimensions |
250*200*60(mm) |
|
Many kinds of clamps for your choice:
